E GRAN X Junction Boxes

stainless steel

Optimised cable management, even in harsh environments: The junction boxes allow easy and smooth management of electrical cables and facilitate access to wiring for checks, repairs, or future modifications.

Material: AISI 304L stainless steel sheet (AISI 316L on request)

Remarkable structural rigidity and performance, thanks to the production of panels with formed corners, no longer welded, and a silicone gasket.

Equipotentiality between the panel and the enclosure, allowing grounding between the two.

Wiring support, thanks to the optimised p.a. plate, with more surface area and space for wiring.

Maintenance of IP rating, thanks to the gasket and enclosure caps

Ease of use and safety, thanks to the innovative panel locking system, with 1/4 turn anti-slip screws.

Harmonic solution design, with dedicated stainless steel fixing brackets.

Technical Features

Material:

Enclosure and panel: AISI 304L stainless steel sheet (AISI 316L on request)
Screws: Stainless steel
Thickness: Casing and panel 1.2mm

Sealing gasket: Two-component silicone foam, maintaining IP rating

Degree of protection: IP66, IP69K, NEMA/UL TYPE 1, 12, 4x

Impact resistance rating: IK10

Complementary Accessories

Internal mounting plate
Internal DIN profiles
Hinges
Wall mounting kit

Discover our accessories

Insights

To order the enclosure in AISI 316L version, add the suffix H to the code
Also available in painted sheet metal, in different versions: E GRAN
