AE, LE, PE, ME Modular Control Desks
PAINTED SHEET STEELAE Base
Technical Features
Material
- Enclosure and door: Press-bent DC01 sheet steel
- Mounting plate: Sendzimir sheet steel
- Thickness: Enclosure and door: 1.5 mm, base plate: 2.5 mm
Painting: Standard electrostatic E DUP cycle - liquid painting by cathodic electrophoresis process with epoxy resin and finishing with thermosetting epoxy-polyester powders.
Colour: Textured RAL7035
Sealing gasket: Two-component polyurethane foam, allowing the IP rating to be maintained
Degree of protection: IP55, NEMA/UL Type 1, 12, 3R
Impact resistance rating: IK10
Supply
- Enclosure
- Front door (for base P=500mm, front door and rear door) with side stiffening strip and double flap locking system diam. 3.0mm
- Mounting plate
- Adjustable cable entry
To complete the configuration: TL cover and modular plinth
LE Shelf
Technical Features
Material:
- Enclosure and upper panel: Press-folded DC01 sheet steel
- Profiles: Sendzimir steel sheet
- Thickness: Casing 1.5 mm, top panel 2.0 mm
Painting: Standard electrostatic E DUP cycle - liquid painting by cathodic electrophoresis process with epoxy resin and finishing with thermosetting epoxy-polyester powders
Colour: Textured RAL7035
Sealing gasket: Two-component polyurethane foam, allowing the IP rating to be maintained
Degree of protection: IP55, NEMA/UL Type 1, 12, 3R
Impact resistance rating: IK10
Supply
- Enclosure
- Upper panel complete with 3.0 mm diameter double flap closure system, profiles, and gas springs preventing accidental closure
- Sealing gasket
- Mounting accessories
PE Upper Part
Technical Features
Material
- Enclosure and front panel: Press-folded DC01 sheet steel
- Mounting plate and vertical profiles: Sendzimir sheet steel
- Thickness: Casing 1.5 mm, base plate 2.5 mm, profiles 2.0 mm, front panel 2.0 mm
Painting: Standard electrostatic E DUP cycle - liquid painting by cathodic electrophoresis process with epoxy resin and finishing with thermosetting epoxy-polyester powders.
Colour: Textured RAL7035
Sealing gasket: Two-component polyurethane foam, allowing the IP rating to be maintained
Degree of protection: IP55, NEMA/UL Type 1, 12, 3R
Impact resistance rating: IK10
Supply
- Enclosure
- Flip-up front panel (for lift P=500mm flip-up front and rear panel), complete with 3.0mm diameter double fin locking system, vertical profiles, and mechanical stop on opening
- Mounting plate with adjustment profiles
- Sealing gasket
- Mounting accessories
ME Shelf
Technical Features
Material:
- Enclosure and upper panel: Press-folded DC01 sheet steel
- Profiles: Sendzimir steel sheet
- Thickness: Casing 1.5 mm, top panel 2.0 mm
Painting: Standard electrostatic E DUP cycle - liquid painting by cathodic electrophoresis process with epoxy resin and finishing with thermosetting epoxy-polyester powders
Colour: Textured RAL7035
Sealing gasket: Two-component polyurethane foam, allowing the IP rating to be maintained
Degree of protection: IP55, NEMA/UL Type 1, 12, 3R
Impact resistance rating: IK10
Supply
- Enclosure
- Upper panel complete with 3.0 mm diameter double flap closure system, profiles, and gas springs preventing accidental closure
- Sealing gasket
- Mounting accessories
Modular Control Desks
Code List
Filter by:
| Item # | Configuration | Height | Width | Depth | Add to Quote Cart |
|---|---|---|---|---|---|
| AE123 | Console base | 770 | 1200 | 400 | |
| AE1235 | Console base | 770 | 1200 | 500 | |
| AE164 | Console base | 770 | 1600 | 400 | |
| AE1645 | Console base | 770 | 1600 | 500 | |
| AE601 | Console base | 770 | 600 | 400 | |
| AE802 | Console base | 770 | 800 | 400 | |
| AE8025 | Console base | 770 | 800 | 500 | |
| LE123 | Top desk | 200 | 1200 | 835 | |
| LE1235 | Top desk | 200 | 1200 | 935 | |
| LE164 | Top desk | 200 | 1600 | 835 | |
| LE1645 | Top desk | 200 | 1600 | 935 | |
| LE601 | Top desk | 200 | 600 | 835 | |
| LE802 | Top desk | 200 | 800 | 835 | |
| LE8025 | Top desk | 200 | 800 | 835 | |
| ME123 | Top desk | 300 | 1200 | 650 | |
| ME1235 | Top desk | 300 | 1200 | 750 | |
| ME164 | Top desk | 300 | 1600 | 650 | |
| ME1645 | Top desk | 300 | 1600 | 750 | |
| ME601 | Top desk | 300 | 600 | 650 | |
| ME802 | Top desk | 300 | 800 | 650 | |
| ME8025 | Top desk | 300 | 800 | 750 | |
| PE123 | Upper part | 460 | 1200 | 400 | |
| PE1235 | Upper part | 460 | 1200 | 500 | |
| PE164 | Upper part | 460 | 1600 | 400 | |
| PE1645 | Upper part | 460 | 1600 | 500 | |
| PE601 | Upper part | 460 | 600 | 400 | |
| PE802 | Upper part | 460 | 800 | 400 | |
| PE8025 | Upper part | 460 | 800 | 500 |
Contact our team of experts to discuss your project requirements and request a quote today.
